Intelligent full pressure start controller, 0.75-22KW motor pumps developed a new high-performance products, mainly for single pump start control box, as an intelligent supporting the use of foreign aid may be subject to control (eg: float, electricity pressure gauge, electrodes, and automatic with manual selection, simplifies the manual distribution box control line work, integrated relays and · the water level control functions, modern small pump intelligent control the optimal choice.

A protection function: phase protection, phase unbalance protection, overload protection.
1. phase protection: When the three-phase motor power in any one phase-phase or phase inside the motor off, the protection action lag time ≤1S.
2. phase unbalance protection: When the motor’s three-phase power to any two-phase current difference of more than (50 ± 10)%, the protection action lag time ≤1S.
3. Overload protection: When the motor current reaches the rated value of 1.2 times to 6 times, the protector of the action lag time of 80S ~ 10S (inverse time characteristics).
B output interface Reset: power control loop reset; reset time: (60 ± 10) S.
C Work: continuous work style.
D Voltage range: AC24V ~ 380V / 45 ~ 60Hz.
